Stainless steel dutch wire mesh is also known as stainless steel dutch woven wire cloth and stainless steel filter cloth,dutch weave mesh,its mainly feature is the warp and weft have a great contrast to wire diameter and density,so the mesh thickness and the filtration precison and service life for square hole mesh has the the oibvious enhancement.
Materials: 302,304,304L,316,316L stainless steel wire.
Stainless steel dutch woven wire cloth offers good wear-resistance, acid-resistance, heat-resistance and corrosion resistance. It also has fine filtration and highly durable construction.
Applications:
Due to its stable and fine filtration capability, stainless steel dutch wire mesh is extensively utilized as filter fittings for chemical industry, medicine, petroleum, telecom-communication and scientific research units, for example, filtering and screening in airspace, oil and chemicals, such as filter candles, vacuum filters and spring filters.
| Mesh | Wire Dia. (MM) | Material (AISI) |
| 12mesh × 64mesh | 0.58 × 0.40 | 304 or 316 |
| 24mesh × 110mesh | 0.36 × 0.25 | 304 or 316 |
| 14mesh × 88mesh | 0.50 × 0.33 | 304 or 316 |
| 30mesh × 150mesh | 0.23 × 0.18 | 304 or 316 |
| 40mesh × 200mesh | 0.18 × 0.13 | 304 or 316 |
| 50mesh × 250mesh | 0.14 × 0.11 | 304 or 316 |
| 80mesh × 700mesh | 0.10 × 0.08 | 304 or 316 |
| 165mesh × 800mesh | 0.071 × 0.040 | 304 or 316 |
| 165mesh × 1400mesh | 0.06 × 0.04 | 304 or 316 |
| 200mesh × 1800mesh | 0.05 × 0.032 | 304 or 316 |
| 825mesh × 2300mesh | 0.035 × 0.025 | 316L |
| 400mesh × 2800mesh | 0.030 × 0.02 | 316L |
