Epoxy Wire Mesh usually used in air filters, especially for auto or cars etc,as support for filtering septum. This mesh assure good results in pleating, saving the coating stability.
Special size is available on request.
Features: Epoxy coated steel wire mesh has light weight, good flexibility, good corrosion resistance and ventilation, easy cleaning, good bright and environmental friendly.
Application: Epoxy coated steel mesh is mainly used in oil filter, oil sand control tube, hydraulic oil filter, filter supporting wire mesh and other industrial uses.
Epoxy Coated Steel Wire Mesh is used as support for filtering septums.
This mesh assures good results in pleating,saving the coating stability.
Usually used in oleodynamic and air filters applications.
|Mesh||Wire Dia.||Width m||Length m|
|12 × 10||0.28mm||0.5-1.5||150 / 200 / 300|
|18 × 14||0.18mm||0.5-1.5||150 / 200 / 300|
|18 × 14||0.28mm||0.5-1.5||150 / 200 / 300|
|24 × 24||0.18mm||0.5-1.5||150 / 200 / 300|
|30 × 30||0.18mm||0.5-1.5||150 / 200 / 300|
|18 × 16||0.28mm||0.5-1.5||150 / 200 / 300|
